openBrushograph painting tools for brushes, inks & improvised machines.

openBrushograph grows out of the Brushograph experiments in "brushology" – playful ways of painting with a mechatronic brush. It brings together low-cost CNC mechanics, open source software, brush heads, inks and hacked-together controllers. Here you will find firmware extensions, software tools, workshop files and documentation for openBrushograph machines and related experiments.

★ Browse projects on GitHub Source of this site
Brushograph Studio mechatronics
Mechatronic web interfaces & sonic experiments — stepper-motor synths, drawing pads, drone engines and G-code sequencers.
G-Code Archive gallery
Browse the global collection of over 1100 curated Brushograph G-codes. Search, preview, download, and sync your favorites.
Ultra Painter concentric / lines
Full raster-to-G-code painter with concentric and lines infill, path optimization, backlash compensation and dip cycles.
4-Channel Painter multi-color
Multi-color robotic painting studio — four image layers, per-channel dip stations, tutti frutti mode and path visualizer.
Batak Assembler Gorga
Construct Batak script text paths from skeletal definitions. Generates vector paths for plotting.
Studio Curated G-Codes View Full Archive →
Loading archive...
Generative art
NirmanaFlow NEW
Generative flow field art for plotters. Create organic textures and patterns directly in the browser.
Legacy tools
brushograph.pro main web UI
The primary web interface for converting images and vectors into brush-friendly G-code toolpaths.
Raster-painter image → G-code
Generate FluidNC raster G-code from images, with brush dipping, wiping and optional X/Y backlash compensation.
PaintByNumbers numbered passes
Turn separated regions or colors into numbered painting passes with brush-friendly G-code output.
Raster_plotter variable Z
Experimental raster plotting with variable Z heights for brush pressure / height effects.
backlash_fix X/Y compensation
Post-process G-code to insert correction moves on X/Y direction changes, compensating mechanical backlash.
lb2gcode LightBurn colors
Add color pick-ups, washing sequences and brush refreshes to LightBurn G-code using layer names.
